2025R Compact Tractor

Specifications

Compare >>> Select up to 2 models to compare specifications

John Deere2025R Compact Tractor

Add Model --Please Select-- 2032R (Model year 2024) 2038R (Model year 2024) CK2610 HST B2601 B2650

Add Model --Please Select-- 2032R (Model year 2024) 2038R (Model year 2024) CK2610 HST B2601 B2650

Engine power (gross)	SAE J1995 rated power: 17.8 kW 23.9 hp 24.2 PS at 3200 rpm
Power take-off (PTO) power	12.8 kW 17.2 hp
Steering hydraulics	13.4 L/min 3.5 gpm
Implement hydraulics	13.4 L/min 3.5 gpm
Hitch type	Limited Category 1
Lift capacity, 24-in. behind link arms	415 kg 915 lb
Standard transmission; forward/reverse	Hydrostatic - two range
Cruise control	Standard
Approximate shipping weight (open-station; cab)	Open station: 849 kg 1872 lb Cab: 1085 kg 2392 lb
Wheelbase	1600 mm 63 in.

Family
Manufacturer	Yanmar®
Engine model	3TNV80F-NCJT
Engine power (gross)	SAE J1995 rated power: 17.8 kW 23.9 hp 24.2 PS at 3200 rpm
Power take-off (PTO) power	12.8 kW 17.2 hp
Rated engine speed	3200 rpm
Type	Diesel
Injection pump type	Indirect injection
Aspiration	Natural
Emissions compliance	Final Tier 4
Cylinders/displacement	Three cylinders: 1.267 L 77 cu in.
Number of cylinders	Three
Cylinder liners	Cast-in-block
Bore and stroke	80 x 84 mm 3.2 x 3.3 in.
Compression ratio	23.1:01
Lubrication	Pressurized
Cooling system	Water pump
Air cleaner	Dual element
Engine torque at rated speed	53.1 Nm 39.1 lb-ft
Fuel tank capacity	20.4 L 5.39 gal.

Battery size	500 CCA
Alternator (12-V)	40 amp
Starter size	1.2 kW 1.6 hp

Type	Indirect injection
Fuel consumption

Standard transmission; forward/reverse	Hydrostatic - two range
Optional transmission; forward/reverse
Left-hand reverser	No
Transmission gear ranges
Final drive	Spur gear
Brakes	Wet disc
Steering	Power steering
Clutch, wet/dry
Clutch disk diameter wet clutch
Axle capacity	Front 612 kg 1349 lb Rear 1100 kg 2425 lb
Creeper	No
Cruise control	Standard
Differential lock	Yes
Drawbar maximum vertical load

Type	Open center
Pump rated output	Steering 13.25 L/min 3.5 gpm Implement 13.25 L/min 3.5 gpm 26.5 L/min 7.0 gpm
Pump type	Gear
Maximum operating pressure	137 bar 1987 psi
Draft control sensing	Position control
Remote control valves available	Two

Type	Limited Category 1
Lift capacity, 24-in. behind link arms	415 kg 915 lb

Standard	Rear - 540 rpm Mid - 2100 rpm
Optional
Control	Independent
Clutch	Wet disk
Brake (for mid and rear PTO)	Wet disk
Engagement method

Crankcase with filter	2.7 L 2.9 gal.
Transmission and hydraulic system

Type	Spur gear
Differential lock	Yes

Rollover protective structure	Type Foldable OSHA, SAE, ASAE
Platform - flat/straddle	Three-piece semi flat
Gear shift location - console/floor	Left-hand side

Compliance
Visibility
Air conditioning, temperature differential
Doors
Noise rating
Seat equipment

Height
Wheelbase	1600 mm 63 in.
Front axle clearance
Turning radius with brakes
Turning radius without brakes	Outside front tire: 2.51 m 8.2 ft
Limited slip differential	No
Approximate shipping weight (open-station; cab)	Open station: 849 kg 1872 lb Cab: 1085 kg 2392 lb

Front	R3 Turf: 23x8.50-12 R3 Radial: 220/55-R12 R4 Industrial: 23x8.50-12
Rear	R3 Turf: 12-16.5 R3 Radial: 280/70 R16 R4 Industrial: 12-16.5
Front tread range
Rear tread spacing

Toolbox	Yes
Tilt steering wheel	Yes
12-V Outlet	Yes
