4044M Compact Utility Tractor

Specifications

Compare >>> Select up to 2 models to compare specifications

John Deere4044M Compact Utility Tractor

Add Model --Please Select-- 3046R (Model year 2024) 4044R HST/PRT (Model year 2024) 4052M HST/PRT (Model year 2024) 4052R HST/PRT (Model year 2024) 4066M (Model year 2024) Gear 4WD / HST 4WD 4066R (Model year 2024) Gear 4WD / HST 4WD Boomer 41

Add Model --Please Select-- 3046R (Model year 2024) 4044R HST/PRT (Model year 2024) 4052M HST/PRT (Model year 2024) 4052R HST/PRT (Model year 2024) 4066M (Model year 2024) Gear 4WD / HST 4WD 4066R (Model year 2024) Gear 4WD / HST 4WD Boomer 41

Engine power (gross)	SAE J1995 rated power: 31.7 kW 42.5 hp 43.1 PS at 2600 rpm
Power take-off (PTO) power	PowrReverser™ transmission: 25 kW 33.6 hp eHydro™ transmission: 24.1 kW 32.3 hp Per SAE J1995
Steering hydraulics	23.5 L/min 6.2 gpm
Implement hydraulics	42.3 L/min 11.2 gpm
Hitch type	Category 1
Lift capacity, 24-in. behind link arms	1135 kg 2500 lb
Standard transmission; forward/reverse	PowrReverser transmission
Cruise control	Optional
Approximate shipping weight (open-station; cab)	Open operator station (OOS): 1705 kg 3759 lb Cab: Not applicable
Wheelbase	185.5 cm 73 in.

Family	EYDXL2.19NDA FYDXL2.19NDA GYDXL2.19NDA
Manufacturer	Yanmar®
Engine model	4TNV88C-MJT
Engine power (gross)	SAE J1995 rated power: 31.7 kW 42.5 hp 43.1 PS at 2600 rpm
Power take-off (PTO) power	PowrReverser transmission: 25 kWh 33.6 hp eHydro transmission: 24.1 kW 32.3 hp Per SAE J1995
Rated engine speed	2600 rpm
Type	Diesel
Injection pump type	High pressure common rail direct injection
Aspiration	Natural
Emissions compliance	Final Tier 4
Cylinders/displacement	4 / 2.189 L 4 / 133.5 cu in.
Number of cylinders	Four
Cylinder liners	Cast-in-block
Bore and stroke	88x90 mm 3.46x3.54 in.
Compression ratio	19.1:1
Lubrication	Pressurized
Cooling system	Liquid
Air cleaner	Dual element
Engine torque at rated speed	116 Nm 85.6 lb-ft
Fuel tank capacity	56.9 L 15 U.S. gal.

Battery size	770 CCA
Alternator (12-V)	75 amp
Starter size	2 kW 2.68 hp

Type	High pressure common rail direct injection
Fuel consumption

Standard transmission; forward/reverse	PowrReverser transmission
Optional transmission; forward/reverse	eHydro transmission
Left-hand reverser	PowrReverser transmission only
Transmission gear ranges	12F/12R PowrReverser Infinitely-variable, three range
Final drive	Planetary
Brakes	Multi-plate wet disc
Steering	Hydrostatic power steering
Clutch, wet/dry	Wet
Clutch disk diameter wet clutch	129 mm 5.08 in.
Axle capacity	Front 1600 kg 3528 lb Rear 2400 kg 5292 lb
Creeper	No
Cruise control	Optional
Differential lock	Yes
Drawbar maximum vertical load

Type	Open center
Pump rated output	Steering 23.5 L/min 6.2 gpm Implement 42.3 L/min 11.2 gpm 65.8 L/min 17.4 gpm
Pump type	Single gear
Maximum operating pressure
Draft control sensing	Position control
Remote control valves available	Up to six rear remotes

Type	Category 1
Lift capacity, 24-in. behind link arms	1135 kg 2500 lb

Standard	Independent 540 rpm at 2600 rpm
Optional
Control	Position
Clutch	Wet disc
Brake (for mid and rear PTO)
Engagement method

Crankcase with filter	5.3 L 1.4 gal.
Transmission and hydraulic system	47.3 L 12.5 gal.

Type	Planetary
Differential lock	Yes

Rollover protective structure	Type Foldable Yes
Platform - flat/straddle	Flat
Gear shift location - console/floor	PowrReverser - Left-hand side

Compliance
Visibility
Air conditioning, temperature differential
Doors
Noise rating
Seat equipment

Height
Wheelbase	185.5 cm 73 in.
Front axle clearance	35.1 cm 13.8 in.
Turning radius with brakes	2.8 m 9.19 ft
Turning radius without brakes	3.0 m 9.84 ft
Limited slip differential
Approximate shipping weight (open-station; cab)	OOS: 1705 kg 3759 lb Cab: Not applicable

Front	Farm - 8-16 Turf - 27x10.5-15 or 27x12LL-15 Industrial - 10-16.5
Rear	Farm - 13.6-28 Turf - 44x18-20 or 22.5LL-16.1 Industrial - 16.9Lx24
Front tread range	148.1 cm 58.3 in.
Rear tread spacing	137.2 cm 54 in.

Toolbox
Tilt steering wheel
12-V Outlet
